El-bjørn Varmeblæser fast montage vf9f2

Electric bear stationary fan heaters are intended for fixed mounting on the wall using wall brackets, which are supplied. The housing is made of corrosion-resistant, powder-coated aluzinc sheets. It is possible to adjust the air direction to 20° downwards.
VF 9F2 and VF 15F2 are used in dry, damp and wet rooms such as workshops, warehouses, washing and spray rooms, but are not intended for fire and explosion hazardous environments.
VFBR 9F2can also be installed in flammable rooms in e.g. the textile and woodworking industries and stables.
All types are in protection class IP55 and are equipped with temperature sensor, which protects against overheating.
The fan heaters must be installed with separate thermostat and switch boxes to achieve the desired function.

Control and regulation:
For regulation of the fan heaters, external switch and thermostat boxes are supplied, which must be ordered separately.
For VFBR 9F2, switch box OKB 55-1.
For VF 9F2 and VF 15F2, switch box OKB 55-2.

is used. For all types, thermostat box TB 55-1 is used, where the temperature can be regulated from 5-35° C.

If the thermostat box is deselected, the terminals for the thermostat can be connected and the fan heater will constantly run with heat when it is in operation.

Link to manufacturer:
El-bjørn
El-bjørn

Airflow	1200 m³/h
Connection voltage	400 V
Device of an external thermostat	Yes
Drying options	No
Food contact material	No
Heat output	0 - 9 kW
Number of power levels	1
Overheating protection	No
Portable	No
Protection class (IP)	IP55
REACH – contains substances from the Candidate List?	No
Recording effect	9 kW
RoHS compliant	Yes
Time switch	No
UNSPSC	40101818
Ventilation position	No
With fan regulation	No
With room thermostat	No
