Pettinaroli Klapkontraventil 1/2
Main image
Click to view image in fullscreen
![]()
Flap check valve 1/2'' red goods
Non-stock item - Expected shipment 02-04-2026 - if you order today
↻
Updating inventory, please wait...
Last Updated:
EAN
8016603012625
Supplier no.
0243027206
Type no.
184MO-004
VVS No.
430377704
Price per Styk
€10.95
Excl. Tax:
€8.76
Excl. Tax:
Excl. Tax:
Regular Price
€29.48
Min. order 1 Styk
Description / Pettinaroli Klapkontraventil 1/2
Metal disc flap valve, brass
Recommended operating temperature/maximum pressure
6 bar - 90°C
Recommended operating temperature/maximum pressure
6 bar - 90°C
Link to manufacturer:
Pettinaroli
Pettinaroli
More Information
| Backlash flap angle | 90 ° |
| Brand | PETTINAROLI |
| Connections | Indvendigt Rørgevind konisk (NPT) |
| Country of origin | IT - Italy |
| Default | DIN |
| Description | 184MO-004 |
| EAN number | 8016603012625 |
| External pipe diameter, all connections | 21.8 mm |
| Food contact material | No |
| Gasket | Other |
| Height (mm) | 50 mm |
| Length connection 1 | 10 mm |
| Length connection 2 | 10 mm |
| Material enclosures | Messing |
| Material for housing | Bronze |
| Material quality | Other |
| Maximum mean temperature (continuous) | 100 °C |
| Maximum pressure at 20 gr. C | 10 bar |
| Maximum working pressure at 20 gr. C | 10 bar |
| Minimum medium temperature (continuous) | 5 °C |
| Net weight | 188,00 g / STK |
| Nominal diameter | 1/2" |
| Pack size | 10 |
| Pressure class | PN 10 |
| Pressure stage flange | PN 10 |
| Product code | 270129244 |
| Protection class | Other |
| REACH – contains substances from the Candidate List? | No |
| Real working length connection 1 | 10 mm |
| Real working length connection 2 | 10 mm |
| Standard | Other |
| Stock item | No |
| Surface treatment | Ubehandlet |
| Type | Lige |
| Unit | STK |
| UNSPSC | 40141604 |
| Valve shape | Kegle |
| VVS number | 430377704 |
