Siemens Rccb type b 40/4 30ma 4Mw
Main image
Click to view image in fullscreen
![]()
Residual current operated circuit breaker, 4-pole, Type B, short-term delayed, In: 40 A, 30 mA, Un AC: 400 V
2 Piece on stock (day-to-day delivery)
↻
Updating inventory, please wait...
Last Updated:
EAN
4001869549033
Supplier no.
2622704915
Type no.
5SV3344-4
Price per Styk
€433.73
Excl. Tax:
€346.98
Excl. Tax:
Excl. Tax:
Regular Price
€709.70
Min. order 1 Styk
Description / Siemens Rccb type b 40/4 30ma 4Mw
More Information
| Ambient temperature during operation | -25 - 45 °C |
| Brand | SIEMENS |
| Conditional rated short-circuit current | 3 kA |
| Country of origin | DE - Germany |
| Degree of pollution | 2 |
| Description | 5SV3344-4 |
| EAN number | 4001869549033 |
| EC-numbers | 231‑100‑4, 215‑267‑0 |
| EL number | 2622704915 |
| Expandability | Yes |
| Explosion-proof | No |
| Fault current type | B |
| Food contact material | No |
| Frequency | 50 Hz |
| Installation depth | 70 mm |
| Installation method | DIN-skinne |
| Max conductor cross-section multithreaded | 0.75 - 35 mm² |
| Max conductor cross-section single-threaded | 0.75 - 35 mm² |
| Module width | 4 |
| Net weight | 450,00 g / STK |
| Number of poles | 4 |
| Pack size | 1 |
| Power loss | 2.5 W |
| Product code | 270118172 |
| Protection class (IP) | IP20 |
| RAL number (related) | 7035 |
| Rated current | 40 A |
| Rated fault current | 0.03 A |
| Rated insulation voltage Ui | 2000 V |
| Rated rated voltage (Uimp) | 6 kV |
| Rated voltage | 400 V |
| REACH – contains substances from the Candidate List? | Yes |
| RoHS compliant | Yes |
| Selective protection | No |
| Series | SENTRON |
| Short circuit breaking performance | 10 kA |
| Stock item | Yes |
| Type number | 5SV |
| Type of corend delay | Yes |
| Unit | STK |
| UNSPSC | 39121601 |
| Voltage type | AC |
| With locking mechanism | Yes |
