Ta Globo d-sb dn15 kuglehane
Main image
Click to view image in fullscreen
![]()
IMI, GLOBO D-SB, Ball valve with ball made of stainless steel for domestic water, DN 15
2 Piece on stock (day-to-day delivery)
↻
Updating inventory, please wait...
Last Updated:
EAN
4024052974511
Supplier no.
5401033060
Type no.
32701010406
Price per Styk
€34.08
Excl. Tax:
€27.26
Excl. Tax:
Excl. Tax:
Regular Price
€76.51
Min. order 1 Styk
Description / Ta Globo d-sb dn15 kuglehane
More Information
| Ball sealing material | PTFE |
| Bottling option | No |
| Brand | TA |
| Bullet material | Rustfri stål |
| Connection 1 | Indvendig gevind Rp, cylindrisk (ISO7-1) |
| Connection 2 | Indvendig gevind Rp, cylindrisk (ISO7-1) |
| Description | 32701010408 |
| Design | 1-stykke |
| Dimension connection 1 | 1/2"" |
| DVGW signing | Yes |
| EAN number | 4024052974511 |
| Food contact material | No |
| Height handle | 89 mm |
| Key width | 27 mm |
| KIWA certified | No |
| Length handle | 149 mm |
| Material enclosures | Bronze |
| Material quality | Bronze (Rg 5) |
| Maximum pressure difference at 20 °C | 16 bar |
| Mean temperature (continuous) | -10 - 120 °C |
| Medically clean | No |
| Nominal diameter connection 1 | 1/2" |
| Nominal diameter connection 2 | 1/2" |
| Operation | Håndtag |
| Pack size | 1 |
| Pressure class | PN 16 |
| Primary spindle sealing material | EPDM |
| REACH – contains substances from the Candidate List? | No |
| Real working length connection 1 | 32.5 mm |
| Real working length connection 2 | 32.5 mm |
| Rectifier current | None |
| RoHS compliant | No |
| Secondary spindle sealing material | EPDM |
| Series | GLOBO |
| Stock item | Yes |
| Surface protection, housing | None |
| Unit | STK |
| UNSPSC | 40141607 |
| Valve angle | 90 ° |
| VdS-controlled | No |
| VVS number | 417970304 |
| With bottling | No |
| With check valve | No |
| With filter | No |
| With insulation sheath | No |
| With switching connection 1 | No |
| With switching connection 2 | No |
