Viega Raxofix easytop kuglehane. 32mm raxofix

Use

Ball valve with SC 32 mm Raxofix press connection
Silicon bronze valve body according to DIN 50930-6 / DIN EN 1982, maintenance-free spindle, stainless steel ball, T-?shaped handle with replaceable media marking green/red

Raxofix from Viega is a pressure loss-optimised pipeline system in plastic with a new and innovative technology - the "raxial"
pressing technique. For the first time, it combines pressing and sliding technology effectively: Raxofix pipeline systems consist of high-quality red goods press fittings with durable PPSU support bushings and Raxofix plastic pipes.

The system has a high flow level, which is far superior to the traditional
plastic pipe systems on the market. The result is: lower
costs, improved hygiene and greater user-friendliness, and the possibility of a dimensioning of 16 mm at floor level.

Remember that for the Raxofix system, Combi PB pipes are used from the distributor to the pex can

Technical data

• Silicon bronze valve body according to DIN 50930-6 / DIN EN 1982
• operating pressure max. 1,6 MPa (PN 16)
• operating temperature max. 110 °C
• with DVGW authentication
• Possibility of a dimensioning of 16 mm at floor level.
• Model 5375
