Weidmüller Gennemgangskl. zdu 4 163205

Pass-through clamp 4mm² spring terminal ZDU 4 beige

336 Piece on stock (day-to-day delivery)

EAN 4008190263188

Supplier no. 7921000784

Type no. ZDU 4

Regular Price €2.39

Min. order 1 Styk

Styk

Description / Weidmüller Gennemgangskl. zdu 4 163205

Link to manufacturer:
Weidmüller
Weidmüller

Colour	Beige
Completion stage required	Yes
Connection position	Over
Depth (mm)	42,6 mm
Electrical connection type 1	Fjederklemme
Electrical connection type 2	Fjederklemme
Explosion tested version 'Ex e'	Yes
Flame retardant class of insulation materials ACC. with UL94	V0
Food contact material	No
Height (mm)	62,4 mm
Height at lowest possible mounting surface	43 mm
Installation method	DIN-skinne 35 mm
Insulating material	Termoplastisk
Internally connected steps	No
Length (mm)	62 mm
Max conductor cross-section finely threaded with tulle	0.5 - 4 mm²
Max conductor cross-section finely threaded without tulle	0.5 - 6 mm²
Max conductor cross-section multithreaded	0.5 - 6 mm²
Max conductor cross-section single-threaded	0.5 - 6 mm²
Number of clamping positions per level	2
Number of levels	1
Operating temperature range	-60 - 130 °C
Rated current I	32 A
Rated voltage	800 V
REACH	No
Width (mm)	6,1 mm
Width/grid dimension	6,1 mm
